Defrost display delay period
Time DDM is shown following defrost termination
Fans do not run during defrost
Evaporator fan restart temperature following defrost
(Only if T2 = EPO)
Maximum evaporator fan stop period following defrost
Minimum evaporator fan stops (following door opening etc)
Evaporator fan mode during thermostatic control:
Temperature based control. When compressor is on, fans are on.
When compressor is off, fans run as long as temperature difference
Te-Ta > FDT. Fans on again with FDH
Time based control. When compressor is on, fans are on. When
compressor is off, fans in accordance to parameters FT1, FT2 and
FT3.
Te-Ta difference for fans to turn off after compressor stopped.
(Only if T2 = EPO and FCM = TMP)
Temperature differential for evaporator fan restart.
(Only if T2 = EPO and FCM = TMP)
Fan stop delay after compressor stop.
Timed fan stop following FT1
(With FT2 = 0 the fans remain on all the time).
Timed fan run following FT2
(With FT3 = 0 and FT2 >0 the fans remain off all the time.
Alarm threshold configuration:
All temperature alarms are inhibited
The value set in ALA and AHA represent actual alarm set points
The values set in ALR and AHR are alarm differentials which relate to
SP and SP + HYS
Low temperature alarm threshold
High temperature alarm threshold
Low temperature alarm differential
(With ALR = 0 the low temperature alarm is excluded)
High temperature alarm differential
(With AHR = 0 the low temperature alarm is excluded)
Air temperature probe used for alarm detection
Evaporator temperature probe used for alarm detection
Delay before alarm temperature warning
Delay before door open alarm warning
