Operation in case of high condenser alarm (T2 = CND)
High condenser temperature alarm inhibited
Condenser warning – „HC‟ displayed, alarm sounds
As „ALR‟ with compressor stopped and defrosts suspended
Condenser alarm temperature (T2 = CND)
Condenser cleaning period.
(With ACC = 0 condenser cleaning is disabled)
Switchover method to second parameter set:
Second parameter set is excluded
Second parameter set is activated/ deactivated by button
Second parameter activated by „heavy‟ usage
Second parameter set activated by D12 input (D12 = IISM)
Minimum limit for IISP setting
Maximum limit for IISP setting
Temperature set point to be achieved in „Mode 2‟
Off/on thermostat differential in „Mode 2‟
Evaporator fan mode during ‘Mode 2’ thermostatic control:
Temperature based control. When compressor is on, fans are on.
When compressor is off, fans run as long as temperature difference
Te-Ta>FDT. Fans on again with FDH
Time based control. When compressor is on, fans are on. When
compressor is off, fans in accordance to parameters FT1, FT2 and
FT3.
Controller sensitivity for switch over between „Modes‟ and 2.
(1 = minimum, 5 = maximum)
Time interval between defrosts in „Mode 2‟.
Standby button operation:
Door switch operation (switch made when door closed):
Configuration digital input operation:
Digital input 2 not activated
High pressure alarm when contact opens
„Mode 2‟ parameters active when contact closes
Defrost initiated when contact closes
Second door switch function (operated „in series‟ with DS)
Digital input 2 not activated
Light output operation is activated/deactivated by button
(With OA1 = LGT)
Light output is switched on when door is opened
(With OA1 = LGT and DS = YES)
Light output is switched off when door is opened.
(With OA1 = LGT and DS = YES)
