Standard CMOS Features
and so on. Use the arrow up/down keys to select an item, then use the <+> or <-> keys to change
the setting.
► Date - <weekday><month><date> <year> format
Day—weekday from Sun. to Sat., automatically displayed by BIOS (Read Only).
Month—month from 1 to 12.
Date—date from 1st to 31st.
Year—year, set up by users.
a value.
► Time - <hour> : <minute> : <second> format
Use <Enter>, <Tab> to move forward and
value.
► IDE Channel 0/1/2/3
These categories identify the hard disks connected to the PATA and SATA ports in the system.
The display of each channel will be different if the setting of On-Chip Serial ATA (in OnChip
IDE Device menu) is set to [Combined], [Enhanced] or [SATA Only] mode. Please refer to
Page 32-33 for detail.
-
[None] means no HDD is installed or set, and [Auto] means the system can auto-detect the
hard disk when booting up. In Access Mode setting, selections of [CHS], [LBA], [Lage] and
[Auto] can help you to select hard drive for legacy compatibility.
Phoenix - AwardBIOS CMOS Setup Utility
Standard CMOS Features
Date (mm:dd:yy) Wed, Item Help
Time (hh:mm:ss)
Press [Enter] to enter
[DVD-ROM DDU1642] next page for detail
x IDE Channel 1 Master None hard drive settings
x IDE Channel 1 Slave None
IDE Channel 2 Master [ None]
IDE Channel 2 Slave [ None]
IDE Channel 3 Master [ None]
IDE Channel 3 Slave [ None]
Drive A [1.44M, 3.5 in.]
Halt On [All , But Keyboard]
Installed Memory
To Next Page
