Chapter 1 Product Introduction
2
915M07 Series User Manual
Main Features
Size
mATX form factor of 9.6 inch x 9.6 inch
Microprocessor
Supports Intel
®
Prescott-T processor in an LGA775 package
Supports FSB at 533 MHz/800 MHz
Supports Hyper-Threading technology
Supports FSB Dynamic Bus Inversion (DBI)
Chipset
Intel
®
915G/P/GV (North Bridge) + ICH6/6R (South Bridge)
System Memory
Four 184-pin DIMM slots
Supports up to 4 GB DDR memory
Supports Dual-Channel DDR 333/400
Registered DIMMs not supported
Supports 256-Mb, 512-Mb, 1-Gb technologies for x8 and x16 non-ECC DDR
devices
USB 2.0 Ports
Supports hot plug
Eight USB 2.0 ports (four rear panel ports, two onboard USB headers
providing four extra ports)
Supports wake-up from S1 and S3 mode
Supports USB 2.0 Protocol up to 480 Mbps transmission rate
Onboard Serial ATA
150 MBps transfer rate
Supports four S-ATA devices
Supports RAID 0, RAID 1, RAID 0+1, Matrix RAID (supported on ICH6R)
