Chapter 1 Product Introduction
6
915M07 Series User Manual
1
2
3
5
6
7
8
ATX 12V connector
This power connector connects the 4-pin 12 V plug from the ATX 12 V power
supply.
CPU socket
LGA 775 Socket T is for the Intel
®
Prescott-T processor.
North Bridge controller
Intel
®
915G/P/GV supports FSB 800/533 MHz, DDR 333/400 MHz, PCI
Express x16 (only for I915G/P). Intel
®
915G/GV provides an integrated gra-
phics accelerator.
DDR DIMM slots
These four 184-pin DIMM slots support up to 4 GB system memory
using unbuffered non-ECC DDR 333/400 DIMMs.
ATX power connector
This 24-pin connector connects to an ATX power supply. The power supply
must have at least 1 A on the +5 V standby lead (+5 VSB).
Floppy disk connector
This connector accommodates the provided ribbon cable for the floppy disk
drive. One side of the connector is slotted to prevent incorrect insertion of
the floppy disk cable.
IDE connector
The IDE connector supports Ultra DMA 100/66, PIO Modes 3 & 4 IDE device.
The connector is slotted to prevent incorrect insertion of the IDE ribbon cable.
Flash ROM
This 4 Mb flash ROM contains the programmable BIOS program.
4
