Chapter 1 Product Introduction
8
915M07 Series User Manual
PCI Express x1 slot
The x1 slot also promises to benefit overall system performance as well,
allowing more throughput to cards currently utilizing the PCI interface. With
more bandwidth at their disposal, cards such as TV tuners, I/O devices, and
other such cards can bring more and better features to the PC.
Audio CODEC (optional)
The ALC655 is an AC’97 CODEC that allows 6-channel audio playback.
The audio CODEC provides six DAC for 5.1 surround sound, S/PDIF output,
CD-IN, Line-in, Line-out and Microphone-in. (For -6 models)
Immersive home theater quality sound experience including Dolby* 7.1
audio capability
The ALC880 is a next generation audio CODEC supporting Intel High
Definition Audio. It supports immersive home theater quality sound experience
including Dolby 7.1 audio capability, and jack re-tasking (only for Front Audio)
capability increases ease-of-use by simplifying audio component installation.
It also supports improved system audio stability with Microsoft Unified Audio
Architecture (UAA) support. (For -8 models)
LAN controller (optional)
The RTL8110S-32 Gigabit Ethernet is a single-chip solution for LAN on
motherboard (LOM) applications, and supports 10/100/1000 Mbps data
transfer rates. (For -K models)
The RTL8100C Ethernet is a single-chip solution for LAN on motherboard
(LOM) applications, and supports 10/100 Mbps data transfer rates. ( For
-L models)
