PC Health Status
► Warning Temperature
This option is used to set the warning temperature for the system. When the temperature of
CPU is higher than the set value, the motherboard will send out warning information.
► Shut Down Temperature
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
This function works only when your operating system is supporting ACPI.
► Case Open Warning
This item is used to enable or disable case open warning function.
► CPU/System Temperature
The CPU/System temperature are automatically detected and displayed by the system.
► CPU Fan/System Fan Speed
The CPU fan/System fan speed are automatically detected and displayed by the system.
► DRAM Voltage/CPU Core/+ 3.3V/+12.0V
The current voltages are automatically detected and displayed by the system.
► CPU Smart Fan Function / System Smart Fan Function
This option is used to enable or disable smart fan function.
► Off PWM TemperatureOff PWM Temperature
It allows you set a temperature value from which smart fan stops its operation.
► Start PWM TemperatureStart PWM Temperature
It allows you set a temperature value from which smart fan starts its operation.
► Start PWM ValueStart PWM Value
It allows you to set an initial PWM value to drive the fan when the temperature reaches Start
value and smart fan begins its operation. The higher PWM value can achieve the faster fan
speed.
► Slope PWM ValueSlope PWM Value
The slope controls the PWM value being stepped up or down versus temperature changes.
CMOS Setup Utility - Copyright (C) 1985-2006, American Megatrends, Inc.
PC Health Status
Warning Temperature [Disabled] Help ItemWarning Temperature [Disabled] Help Item
Shut Down Temperature [Disabled][Disabled]
Case Open Warning [Disabled][Disabled]
CPU Temperature :43:43
o
C/109
o
F
System Temperature :32
o
C/89
o
F DisabledDisabled
CPU Fan Speed :2848 RPM :2848 RPM 50
o
C/122
o
F
System Fan Speed :N/A 5555
o
C/131
o
F
DRAM Voltage :1.888 V 60
o
C/140
o
F
CPU Core :1.296 V 6565
o
C/149
o
F
+3.3V :3.312 V 70
o
C/158
o
F
+12.0V :11.776 V 75
o
C/167
o
F
CPU Smart Fan Function [Disabled] 80
o
C/176
o
F
System Smart Fan Function [Disabled] 85
o
C/185
o
F
90
o
C/194
o
F
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Disabled]
Options
