5
76
5-2 RAID Enable in BIOS
1. Enter the BIOS setup by pressing <DEL> key when boot up.
2. Select the “Integrated Peripherals” from the “Main menu”, then select the “IDE
Conguration” menu and press <Enter> to go to the conguration items.
3. Enable RAID function and individual SATA port for hard drive or DVD connection.
4. Press <F10> to save the setting then PC will reboot itself.
5-3 Select a RAID Array for Use
When BIOS is restarted, it will display a message asking you to press [Ctrl-F] key to
enter the main menu of FastBuild BIOS. Press [Ctrl-F], the Main Menu appears.
CMOS Setup Utility - Copyright (C) 1985-2006, American Megatrends, Inc.
IDE Conguration
IDE CongurationIDE Conguration Help Item
OnBoard PCI IDE Controller [Enabled] Disabled: Disable the
OnChip SATA ChannelOnChip SATA Channel [Enabled] I IDE controller.
OnChip SATA TypeOnChip SATA Type [RAID] Enable: Enable the
IDE controller.
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[RAID]
FastBuild (tm) Utility (c) 2007 Advanced Micro Devices, Inc.
View Drive Assignment. . . . . . . [ 1 ]
Define LD . . . . . . . . . . . . . . . . . [ 2 ]
Delete LD . . . . . . . . . . . . . . . . . [ 3 ]
Controller Configuration . . . . . . [ 4 ]
[ Main Menu ]
Press 1..4 to Select Option [ESC] Exit
