[Disabled]: Disable the integrated IDE controller.

[Enabled]: Enable both IDE controllers.

► OnChip SATA Channel

[Disabled] : Disable SATA ports 1, 2, 3, 4, 5, ESATA.

[Enabled] : Enable SATA ports 1, 2, 3, 4, 5, ESATA.

► OnChip SATA Type

This item is used to set the operating mode of your SATA ports.

Options : [Native IDE]; [RAID]; [AHCI]; [Legacy IDE].

[Native IDE] - This congures the SATA ports to support native IDE mode.

[RAID] - When you enable RAID, it means all your SATA drives must also support AHCI.

[AHCI] - The Advanced Host Controller Interface (AHCI) specication describes the register

level interface for a Host Controller for Serial ATA. The specication includes a description of

the hardware/software interface between system software and the host controller hardware.

AHCI provides more advanced features including SATA features, but some SATA drives may

not support AHCI, unless they are labeled with AHCI support in its specication.

If your motherboard supporting AHCI, and you have a SATA device, which also supports AHCI,

then you can select IDE option to have fair performance (only PATA, SATA level), or you can

select AHCI to get its best performance.

[Legacy IDE] - This congures the SATA ports to support legacy IDE mode which is running

for old Windows system.

► SATA IDE Combined Mode

This item is used to enable or disable the SATA IDE combined mode.

USB Conguration

USB Configuration

Help Item

Module Version - 2.24.3 -13.4 Enable support for

legacy USB.

USB Devices Enabled : Auto option disables

None legacy support if

no USB devices are

connected.

Legacy USB Support

USB 2.0 Controller Mode [High Speed]

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit

F1:General Help F9:Optimized Defaults

[Enabled]

► Legacy USB Support

This item is used to enable the support for USB devices on legacy OS. If you have a USB

keyboard or mouse, set to auto or enabled.

► USB 2.0 Controller Mode
