Foxconn A85GM Series User Manual

3
36
This item is used to set the transmission rate mode of USB 2.0. This function only works under
DOS mode. The available settings are: [High Speed] in 480Mbps; [Full Speed] in 12Mbps.
SuperIO Conguration
CMOS Setup Utility - Copyright (C) 1985-2006, American Megatrends, Inc.
SuperIO Conguration
SuperIO Configuration
Help Item
OnBoard Floppy Controller
[Enabled] Allows BIOS to enable
Serial Port1 Address [3F8/IRQ4] or disable oppy
Serial Port2 Address
[2F8/IRQ3] controller.
Serial Port2 Mode [IrDA]
Serial Port2 Duplex Mode [Half Duplex]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit
F1:General Help F9:Optimized Defaults
[Enabled]
► OnBoard Floppy Controller
This item is used to enable/disable Floppy Controller.
► Serial Port1 Address
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port 1.
► IR IO Address
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port 2.
► IR Mode
This item is used to set the Serial Port2 mode. The available settings are :
[IrDA] : An IrDA device for maximum 115200 bit/s.
[ASK IR] : A faster IrDA for 1152000 bit/s.
► IR Duplex Mode
This item enables you to determine the infrared function of the onboard infrared chip.
