Smart BIOS
► Smart Boot Menu
When PC starts, if [Enabled] is selected, a Boot Menu will be automatically displayed to inform
you to select a boot device. If no device is selected, the rst device will be used. If [Disabled] is
selected, then PC will ask you to press [Esc] key to get into Boot Menu. This setting simplies
multiple boot devices user from pressing [Esc] key to enter boot menu.
► Smart Power LED
Smart Power LED is a feature built on your motherboard to indicate different states during
Power On System Test (POST). The LED is located at the front panel, and it displays POST
state by different long-short blinking intervals. You can always leave this state enabled.
► Current CPU Speed
This item displays the current CPU speed.
► Current FSB Speed
This item displays the current Front Side Bus speed.
► Current CPU Multiplier
This item displays the current CPU Ratio.
► Current DRAM Speed
This item displays the current DRAM speed.
Phoenix - AwardBIOS CMOS Setup Utility
Smart BIOS
Smart Boot Menu
[Disabled] Item Help
Smart Power LED
[Enabled]
Current CPU Speed 1866MHz
Menu Level ►
Current FSB Speed 1066MHz
Current CPU Multiplier 7
Smart Boot menu with a
Current DRAM Speed 800MHz timer to let user to
control boot device
easily
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimized Defaults
Disabled
System Status Power LED Status Stop Blinking Condition
Normal Always On Always On
No Memory Continue blinking On (1sec.), Off (1sec.) Reboot & Memory OK
No Display Continue blinking On (2sec.), Off (2sec.) Reboot & Display OK
Post Error Message
Quick blinking twice (1/3sec. On, 1/3sec. Off),
one long On (1sec.), continuously.
Enter Setup or Skip
No CPU Fan Continue blinking On (1/2sec.), Off (1/2sec.) Reboot & Fan OK
