Foxconn G31MV Series User Manual

TABLE OF CONTENTS
Chapter 1 Product Introduction
Product Specications ..................................................................
2
Layout ...........................................................................................4
Back Panel Connectors ................................................................
5
Chapter 2 Hardware Install
Install the CPU and CPU Cooler .................................................. 8
Install the Memory ...................................................................... 11
Install an Expansion Card ..........................................................13
Install other Internal Connectors ................................................ 14
Jumpers ...................................................................................... 17
Chapter 3 BIOS Setup
Enter BIOS Setup .......................................................................20
Main Menu .................................................................................. 20
System Information ....................................................................22
Fox Central Control Unit ............................................................. 24
Advanced BIOS Features ........................................................... 31
Advanced Chipset Features ....................................................... 33
Integrated Peripherals ................................................................
35
Power Management Setup .........................................................40
PC Health Status ........................................................................43
Load Optimized Defaults ............................................................ 45
Set Supervisor Password ........................................................... 45
Set User Password ..................................................................... 45
Save & Exit Setup ......................................................................45
Exit Without Saving .................................................................... 45
Chapter 4 CD Instruction
Utility CD content ........................................................................ 47
Install driver and utility ................................................................48
FOX ONE
Main Page .............................................................................50

Foxconn G31MV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel G31
Socket	LGA 775
Memory Type	DDR2
Maximum Memory	4 GB
Storage Interface	4 x SATA 3Gb/s, 1 x IDE
Integrated Graphics	Intel GMA 3100
USB Ports	8 x USB 2.0
Memory Slots	2 x DIMM
Expansion Slots	1 x PCIe x16, 2 x PCI
Audio	Realtek ALC662 6-Channel
LAN	Realtek RTL8102E, 10/100 Mbps
CPU Support	Intel Core 2 Quad, Core 2 Duo, Pentium Dual-Core, Celeron
