33
3
Advanced Chipset Features
► System BIOS Cacheable
Select “Enabled” to allow caching of the system BIOS which may improve performance. If any
other program writes to this memory area, a system error may result.
► Video BIOS Cacheable
Select “Enabled” to allow caching of the on board video BIOS which may improve performance.
If any other program writes to this memory area, a system error may result.
** VGA Setting **
► PEG/Onchip VGA Control
This option is used to enable or disable PCI Express graphics card or onboard VGA.
► On-Chip Frame Buffer Size
This pre-allocated memory selection is supplied for legacy VGA and SVGA graphics support
and compatibility. Upon boot, the system BIOS will pre-allocate the amount selected (8MB) from
the top of the main system memory, which will be dedicated for VGA/SVGA graphics. The VGA
graphics memory is needed for applications run from a Microsoft MS-DOS or legacy operating
system, where there is no Intel Graphics Driver loaded.
► DVMT Mode
Dynamic Video Memory Technology (DVMT) dynamically allocates system memory for use
as video memory to ensure the most efcient use of available resources for maximum 2D/3D
graphics performance.
The amount of video memory allocated depends upon the amount requested by the operating
system. When the memory is no longer required, it is returned to the operating system for use by
other applications or system functions. DVMT allocates memory based on system needs. This
BIOS option allows you to adjust the amount of memory available for DVMT.
Fixed is a memory allocation method addition to the Unied Memory Architecture (UMA) concept,
wherein a static amount of page-locked graphics memory is allocated during driver initialization.
This xed amount of memory will provide the user with a guaranteed graphics memory at all
times, and will no longer be available to the OS.
DVMT is an enhancement of the UMA concept, where in the graphics driver allocates memory
Phoenix - AwardBIOS CMOS Setup Utility
Advanced Chipset Features
System BIOS Cacheable
[Enabled] Item Help
Video BIOS Cacheable
[Disabled]
Menu Level ►
** VGA Setting **
PEG/Onchip VGA Control
[Auto]
On-Chip Frame Buffer Size 8MB
DVMT Mode
[DVMT]
DVMT/FIXED Memory Size
[128MB]
Init Display First [PCI Slot]
** PCI Express Relative items **
PCI-E Compliancy Mode
[v1.0a]
Maximum Payload Size
[128]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimized Defaults
Enabled
