► OnBoard FDC Controller
This item is used to enable or disable the onboard FDC controller.
► OnBoard Serial Port 1
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port COM1.
► OnBoard IrDA Port
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard IrDA
port.
► IrDA Duplex Mode
This item enables you to determine the infrared function of the onboard infrared chip.
USB Devices Setting
► USB 1.1 Controller
This item is used to enable or disable the Universal Host Controller Interface for USB.
► USB 2.0 Controller
This item is used to enable or disable the Enhanced Host Controller Interface for USB.
► USB Operation Mode
This item is used to set the USB operation mode. If you select the [High Speed], then the USB
operation mode is determined by the USB device; select [Full/Low Speed], the USB device
operates on full/low speed.
► USB Keyboard Function
This item is used to enable the support for USB keyboard on legacy OS. If you have a USB
keyboard, set to auto or enabled.
► USB Mouse Function
This item is used to enable the support for USB mouse on legacy OS. If you have a USB
mouse, set to auto or enabled.
► USB Storage Function
This option is used to set whether the USB Mass Storage controller is enabled in a legacy
Phoenix - AwardBIOS CMOS Setup Utility
USB Devices Setting
USB 1.1 Controller [Enabled] Item Help
USB 2.0 Controller
[Enabled]
USB Operation Mode [High Speed] Menu Level ►
USB Keyboard Function [Enabled]
USB Mouse Function [Enabled] [Enabled] / [Disabled]
USB Storage Function [Enabled] Universal Host
Controller Interface
*** USB Mass Storage Device Boot Setting *** for Universal Serial
Bus .
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimized Defaults
