can select a value manually such as [667 MHz] or [800 MHz].
► Memory Timing by SPD
This item is used to enable/disable provision of DRAM timing by SPD device. The Serial
Presence Detect (SPD) device is a small EEPROM chip, mounted on a memory module. It
contains important information about the module's speed, size, addressing mode and various
other parameters, so that the motherboard memory controller (chipset) can better access the
memory device.
► Memory Hole
This item is used to determine whether the 15M-16M address eld of memory is reserved for
the ISA expansion card.
► Initial Graphics Adapter
This item is used to choose the initial graphics controller which will be used as the primary
boot device.
► IGD Graphics Mode Select
This item is used to select the amount of system memory used by internal graphics device.
► PEG Port
This item is used to enable/disable PCI Express graphics port.

Foxconn G41MX 2.0 Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
Socket	LGA 775
Maximum Memory	8 GB
Storage Interface	4 x SATA 3Gb/s
USB Ports	8 x USB 2.0
IDE Ports	1 x ATA 100
Video Outputs	1 x VGA
Memory Slots	2 x DIMM
Expansion Slots	1 x PCIe x16, 2 x PCI
Audio	Realtek ALC662, 6-Channel
LAN	Realtek RTL8111 Gigabit Ethernet
Supported CPU	Intel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Memory Type	DDR3
