SuperIO Conguration
► OnBoard Floppy Controller
This item is used to enable/disable Floppy Controller.
► Serial Port1 Address
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port 1.
► Serial Port1 Mode
This item enables you to determine the transfer mode of the serial port 1.
► Serial Port2 Address
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port 2.
► Serial Port2 Mode
This item enables you to determine the transfer mode of the serial port 2.
► Parallel Port Address
This item is used to assign the I/O address for the onboard parallel(or Printer) port.
► Parallel Port Mode
This item is used to assign interrupt request (IRQ) for the onboard parallel (or Printer) port.assign interrupt request (IRQ) for the onboard parallel (or Printer) port. for the onboard parallel (or Printer) port.
► Parallel Port IRQ
This item is used to select the operation modes for the onboard parallel (or Printer) port.
Setting values are: [Normal], [EPP], [ECP] and [EPP+ECP].
► OnBoard CIR Port
This item is used to disable or assign the I/O address for onboard infrared chip.assign the I/O address for onboard infrared chip.onboard infrared chip.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
