► Onboard LAN Controller
This item is used to enable or disable the onboard LAN controller.
► Onboard LAN PXE OpROM
This item is used to enable or disable onboard LAN boot option ROM.
► Azalia HD Audio
This item is enable oe disable the Azalia HD audio.
Super IO
Serial Port 0 Conguration
► Serial Port
This item is used to enable or disable the serial port (COM).
► Device Settings
This item shows the resource assigned to the serial port.
► Change Settings
This item is used to select an optimal settings for the serial port.
► Device Mode
This item is used to change the serial port mode. Options are: [Normal] and [High Speed].
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Super IO Chip IT8772E
Serial Port 0 Configuration
Serial Port [Disabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto]
Device Mode [Standard Serial Po...]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable or Disable Serial Port
(COM)
