► Restore AC Power Loss
This item is used to set which state the PC will take with when it resumes after an AC power
loss.
Health
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
Case Open Warning [Disabled]
CPU Temperature : +46 C
System Temperature : +30 C
CPU Fan Speed : N/A
System Fan Speed : 4470 RPM
CPU Vcore : +1.056 V
DRAM Voltage : +1.596 V
+12V SYS : +11.816 V
+5V SYS : +5.060 V
VBAT : +0.120 V
CPU Shutdown Temperature [Disabled]
CPU Warning Temperature [Disabled]
Smart Fan Function [Disabled]
←: Select Screen
↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enabled Case Open Warning and
open chassis, Intrusion Alarm
will appear. If don’t enter
bios setup and disabled Case
Open Warning one time, Intru
-
sion Alarm don’t clear, it will
appear all the time.
Health
► Case Open Warning
This item is used to enable or disable case open warning function.
► CPU Temperature
These items show the current CPU temperature detected automatically by the system.
► System Temperature
These items show the current System temperature detected automatically by the system.
► CPU Fan Speed
This item shows the current CPU Fan speed detected automatically by the system.
► System Fan Speed
This item shows the current North Bridge Fan speed detected automatically by the system.
► CPU Vcore/DRAM Voltage/+12V SYS/+5V SYS/VBAT
These items show the Current CPU Ccore/DRAM/+12V SYS/+5V SYS/VBAt voltage detected
automatically by the system.
► CPU Shut Down Temperature
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
► CPU Warning Temperature
This option is used to set the warning temperature for the system. When the temperature of
CPU is higher than the set value, the motherboard will send out warning information.
► Smart Fan Function
This option is used to enable or disable smart fan function. Default value is [Disabled].
