Intergrated Clock Chip Conguration
► ICC Enable
This item is used to enable or disable the Integrated Clock Chip(ICC).
► ICC Set Clock Enables
This item is used to enable or disable the ICC Set Clock Enabled.
► Send ICC Lock Registers
This item is used to enable or disable the function of sending ICC Lock Registers message.
► Set Prole
This item is used to enable or disable the ICC prole support.
► Set Prole Index
This item appears only when the Set Prole is enabled, it is used to set ICC prole index.
► ICC OverClocking
Press <Enter> to go to its submenu. It used to change the Integrated Clock Control options.
Options are: [DIV-1S]; [DIV-2S]; [DIV3]; [DIV4]; [DIV-1NS]; [DIV-2NS].
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Integrated Clock Chip Configuration
ICC OverClocking Lib Version 7.0.1.51
Number of ICC Profiles : 1
Current ICC Profile Index : 0
ICC Enable [Enabled]
ICC Set Clock Registers [Enabled]
Send ICC Lock Registers [Enabled]
Set Profile [Enabled]
Set Profile Index 0
▶ ICC OverClocking
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Integrated Clock Chip
Enabled/Disabled.
Chipset
