• RS485/Meter
-
RS485
RS485 is a standard communication interface which can transmit the real time data from inverter to PC or
other monitoring devices.
-
Meter (optional) (Eastron-SDM230-Modbus)
The inverter has integrated export limitation functionality. To use this function, a power meter or a CT must
be installed. For Meter installation, please install it on the grid side.
• DRM0/ESTOP
Note!
For a precise reading and control of power, a meter can be used instead of a CT. If the
CT is fitted in the wrong orientation, anti-backflow function will fail.
Socket asserted by shorting pins
Operate the disconnection device.
Emergency stop the inverter.
