FoxESS H1-3.7-E - AC Output;Input; EPS Output

9
4.3 AC Output/Input
Model
H1-3.0-E
AC1-3.0-E
H1-3.7-E
AC1-3.7-E
H1-4.6-E
AC1-4.6-E
H1-4.6-E1[1]
AC1-4.6-E1[1]
H1-5.0-E
AC1-5.0-E
H1-5.0-E1[1]
AC1-5.0-E1[1]
H1-6.0-E
AC1-6.0-E
AC OUTPUT
Nominal AC power [VA] 3000 3680 4600 4600 5000 5000 6000
Max. apparent AC power [VA] 3300
4048
/3680[2]
5060
/4600[3]
4600 5500 5000 6600
Rated grid voltage
(AC voltage range) [V]
220 / 230 / 240 (180 to 270)
Rated grid frequency [Hz] 50 / 60,
±
5
Nominal AC current [A] 13.0 16.0 20.0 20.0 21.7 21.7 26.1
Max. AC current [A] 14.3 17.6/16[4] 22.0 22.0 23.9 23.9 28.7
Inrush current [A] 9.6A@50us
Maximum output fault
current[A]
130A@ 10us
Maximum output over current
protection(A)
35 36.7 45.8 45.8 47.7 47.7 57.4
Displacement power factor 0.8 leading to 0.8 lagging
Total harmonic distortion
(THDi, rated power)
<3%@ rated power
AC INPUT
Max. AC power [VA] 7000 7680 9600 9600 10000 10000 12000
Max. AC current[A] 31.8 34.9 43.6 43.6 45.5 45.5 54.5
Rated grid voltage
(AC voltage range) [V]
220 / 230 / 240 (180 to 270)
Rated grid frequency [Hz] 50 / 60,
±
5
Note: [1]model for Belgium, [2]3680 for G98, 4048 for other country
[3]4600 for VDE-AR-N 4105, 5060 for other country, [4]16 for G98, 17.6 for other country
4.4 EPS Output
Model
H1-3.0-E
AC1-3.0-E
H1-3.7-E
AC1-3.7-E
H1-4.6-E
AC1-4.6-E
H1-4.6-E1[1]
AC1-4.6-E1[1]
H1-5.0-E
AC1-5.0-E
H1-5.0-E1[1]
AC1-5.0-E1[1]
H1-6.0-E
AC1-6.0-E
EPS OUTPUT (WITH BATTERY)
Max. EPS power [VA] 5000 5000 6000 6000 6000 6000 6000
EPS rated voltage[V],
Frequency [Hz]
230VAC, 50 / 60
EPS peak power[W] 6000, 60s 7200, 60s
Max. EPS current [A] 21.7 21.7 26.1 26.1 26.1 26.1 26.1
Switch time [s] <20ms
Total harmonic distortion
(THDv, linear load)
<2%@ rated power
Note: [1]model for Belgium
