Step 1: Fix the bracket on the wall
Choose the place you want to install the inverter. Place the bracket on the wall and mark the position of
the 5 holes from bracket.
Drill holes with electric drill, make sure the holes are at least 50mm deep, and then tighten the expansion
tubes.
Insert the expansion tubes into the holes and tighten them. Install the bracket with the expansion screws.
