After any adjustment, repair or maintenance, ensure all components are securely tightened.
When lifting the chair, it is strongly recommended to get the user off the chair
before lifting or handling the chair. If absolutely necessary to handle the chair and
yourself together, please exercise extreme caution and have at least two
attendants to assist in lifting the chair. The front and rear edges of the seat base
and frame should be held.
Unfolding
1. As shown in Fig. F1, pull out the chair by holding the
position shown in the figure as directed by the arrows.
F1
2. Rotate the two armrests into position as directed by the
arrow in Fig. F2
F2
F3
3. Pull the backrest to the rear edge of the seat cushion
until the two folding levers reach the red line (Fig. F3).
When a click sound is heard, the chair is unfolded.
26
