Folding
XII.Unfolding and Folding
1. Remove the control panel. (Fig. F8)
F8
2. Press the backrest adjusting button (Fig. F9) and turn the back rest in the direction as shown in
Fig. F10
F9 F10
4.Rotate the armrest as shown in Fig. F11.
F11
5. Loosen the knob as shown in Fig. F12 and turn the leg guard down.
F12
