Pin
BM Lite
pin
Function
Comment
CN2: 1
5
CS_N
CN2: 2
3
MISO
CN2: 3
7
RST
CN2: 4
4
MOSI
CN2: 5
6
IRQ
CN2: 6
2
SPI_CLK
CN3: 1
-
Not connected
CN3: 2
-
Not connected
CN3: 3
-
VDD
CN3: 4
-
Not connected
CN3: 5
-
Not connected
CN3: 6
1, 8
GND
