4
ENGINE TECHNICAL DATA
N45 MNA - N45 MSA
The technical code and serial number are indicated on a plate, which
is located on different parts of the engine, according to the model:
flywheel casing, tappet cover, other.
(*)Net power to the flywheel in compliance with ISO 3046-1. Test
conditions: temperature 25 °C; atmospheric pressure 100 kPa;
relative humidity 30%.
Code N45 MNA/MSA
Engine family F4
Cycle 4-stroke diesel
Number and arrangement
of cylinders
4, in line
Bore x stroke 104 x 132 mm
Total displacement 4,500 cm
3
Air system Natural induction
Injection type Direct with rotating pump
Engine direction of rotation
Anticlockwise
(seen from flywheel side)
Dry weight 380 kg
Electrical system 12 V
Accumulator/s
- capacity
- discharge current
100 Ah or above
650 A or above
Performance (*) N45 MNA/MSA
(TIER 2)
60 kW (81 CV) @ 2,300 rpm
320 Nm (33 Kgm) @ 1,400 rpm
WARNING
Any alteration of the above mentioned characteristics is strictly
prohibited, penalty invalidation of the guarantee and absence of all
liability on the part of FPT .
