12
When there is an alarm signal, the LED
"alarm" lights up and the relevant LED
begins to flash on the control relay.
IMPORTANT NOTICE:
It must not be possible to touch the
applied voltage at the alarm contact. If
this cannot be achieved the voltage
must be earthed, even if it is only small
protective voltage.
The maximum load for the alarm
contact is 250 VAC and 3 Amps.
3.5 Control Contacts
The control voltage of the contactors
should be connected to the terminals "PI"
and "PII". These circuits are potential free.
IMPORTANT NOTICE:
In order not to overload the control
contacts the sum of the holding cur-
rents of all contactor coils connected
may not exceed a value of 5 Amps.
The max. load of the switching con-
tacts is 380 VAC.
In order to maintain the function of the
undervoltage monitoring it is absolutely
necessary to make sure that the control
voltage of the contactors is in the same
phase as the control relay supply.
3.6 Additional Instructions
The installation and connection of the RM
9606 is only finished, once it has been
installed and wired according to these in-
structions.
IMPORTANT NOTICE:
Before commissioning of the control
relay it has to be ascertained that it is
not possible to touch the connecting
terminals (e.g. by means of a locked
door or covering).
The control relay must be kept voltage
free during wiring and installation
works.
