Frama F-Link - Configuration Page Administration - Status

Frama F-Link
19
5.7 Configuration Page Administration – Status
The status of F-Link is showed on the configuration page Administration – Status
3
.
F-Link state: Description:
Ready To Connect
F-Link is in operation. A connection to the FO2 backend system can be start-
ed.
Connected
F-Link is connected to the FO2 backend system and transfers data.
Ready No Internet
F-Link is in operation, but has no connection to the internet via the wired or
wireless network.
HTTP Error F-Link is in operation, but a HTTP error has occurred when F-Link connected
to the FO2 backend system.
3
The firmware version name of F-Link V2 (2nd hardware generation) starts with „F-Link2“. At all other
device naming on the website the F-Link version (hardware generation) is not distinguished.
