4.1.4 Static Mode
The F-Link device can operate with a static IP address. The factory default LAN connection type is
DHCP (auto configuration).
Note!
If the F-Link was used with LAN connection type DHCP or STATIC before for connec-
tions, the access to the F-Link configuration page by the Alias IP address 192.168.1.200
and a direct LAN cable is only possible after a reset of F-Link.
Changing to a static IP address over Alias IP address 192.168.200:
1. Connect the F-Link device directly with a LAN cable to a PC
(A cross-wired LAN cable is needed if the PC doesn’t support auto-MDIX).
2. Note the PC LAN network settings for later use.
Set the PC LAN network settings as follow:
IP address: 192.168.1.199
Subnet mask: 255.255.255.0
3. Turn on the F-Link and wait until the Ready LED of the F-Link is permanently on.
4. Open internet web browser on PC.
5. Insert the F-Link default IP 192.168.1.200 into address field.
6. Login with username and password. (Default username: “admin” and password: “admin”).
7. Open configuration page LAN Settings.
8. Change LAN connection type to “STATIC (fixed IP)”.
