Frank FC 711 M - 1 Application; 2 Technical Data

23
UK
1. Application
The FRANK high pressure cleaner is used for the cleaning of machines, vehicles, contai-
ners, sanitary installations, oors and walls as well as for cleaning and desinfecting stables
and agricultural factories
2. Technical data
Machinetype
FC 711 M
FC 1024 M
FC 1024 MP
FC1024TCA
Maximum volume ow 11,5 l/min 17 l/min
Maximum operating pressure 115 bar 240 bar
Maximum water supply temperature 70 °C 70 °C
Innite pressure/
volume regulation
50 – 115 bar
7,5 – 11,5 l/min
50 – 240 bar
5,5 –17l/min
Voltage/frequency 230 V 1 AC 60 Hz 400 V 3 AC 60 Hz
Nominal consumption 2,6 kW 7,0 kW
Noise emission,
sound level
max. 72 dB(A)* max. 74 dB(A)*
Dimensions:
Length with trolley 856 mm
Height with trolley 918 mm
Width 545 mm
Weight: without packing 66,0 kg 76,0 kg
Weight: with packing 80,0 kg 90,0 kg
* measured outside, at a distance of 1 m from the machine surface and 1.6 m above the
ground.
