Frank FC 711 M - Working Pressures and Spray Flow Rates

32
5.3 Workingpressuresandsprayowrates
Innite pressure and ow rate regulation by means of overow safety valves. Set desired
operating stage on the handwheel of the overow safety valve:
Admissible nozzles;
Identifcation
Jet shape Angle
Flow rate
l/min
Working
pressure
bar
Recoil
force
N
FC 711 M
0005 Full jet -
11,5 115 20
1505 Flat jet 15 °
2505 Flat jet 25 °
4005 Flat jet 40 °
5005 Flat jet 50 °
6505 Flat jet 65 °
FC 1024 M / MP / TCA
00045 Full jet -
17,0 240 48
15045 Flat jet 15 °
25045 Flat jet 25 °
40045 Flat jet 40 °
50045 Flat jet 50 °
65045 Flat jet 65 °
Working pressure Flow rate
FC 711 M
115 11,5
90 10,0
70 9,0
50 7,5
FC 1024 M / MP / TCA
240 17,0
190 15,0
140 13,0
90 10,5
50 7,5
