2 EXPLANATION OF SYMBOLS
2.1 Symbols used in the manual
2.1.1 Orientation
Symbol Description
Clean components using the 5-step method.
This symbol indicates tips, tricks and additional information
Prerequisites for additional steps
Result or intermediate result for additional steps
2.2 Symbols used in the software
2.2.1 Symbols used for navigation and operation
Symbol Designation Description
Cancel button Cancel preparation
Select next/previous
page
Scroll through menus with multiple pages
Start button Start preparation
2.2.2 Symbols on the dashboard and on the user interface
When a symbol is illuminated on the dashboard, additional information and instructions can be displayed
by tapping the symbol. If an error occurs, refer to the Troubleshooting [ } 78] chapter for help.
Symbol Designation Description
Franke logo Call up the maintenance level
Bean left/right Active grinder

Franke A800 Specifications

General

Type	Automatic Coffee Machine
Material	Stainless Steel
Beverage Options	Espresso, Coffee, Hot Chocolate, Milk Foam, Hot Water
Bean Hopper Capacity	1.2 kg
Power Supply	220-240V, 50/60Hz
Display	10.4-inch touchscreen
Dimensions	340 mm (W) x 600 mm (D) x 750 mm (H)
