Franke Coffee machine Ecolino - Power Connection Ecolino Milk System; Dimensions

1T 310'783 Operating Manual Ecolino / Ecopower Milk System Erstellt: 07.05.2002 Rev.: C SL: 20'987 BJC
page 9
1.1.6 Dimensions Dimensions refrigeration unit
Height 695mm Height 520mm
Width 320mm Width 235mm
Depth 600mm Depth 440mm
Outlet 78 / 148mm
Net weight 48kg (EII 2M HD) Net weight 26kg
1.1.5 Power connection Ecolino Milk System
Basic models Connected load Current
E 1M H CF 2,2kW /10 A 230-240 Vac (PNE)
E 1M HDCF 2,2kW /10 A 230-240 Vac (PNE)
E 2M H CF 2,2kW /10 A 230-240 Vac (PNE)
E 2M HD CF 2,2kW /10 A 230-240 Vac (PNE)
E 1M H CF 1,9kW / 10 A 208 Vac (PNE)
E 1M H D CF 1,9kW / 10 A 208 Vac (PNE)
E 2M H CF 1,9kW / 10 A 208 Vac (PNE)
E 2M H D CF 1,9kW / 10 A 208 Vac (PNE)
Otherwise, the local provisions are binding.
Legend:
1 Power connection (HO5VV-F
PW/80 C13 250V/10A)
2 Water connection (G3/8")
Proceed with care, plastic thread!
Legend:
1 Power connection (HO5VV-F
PW/80 C13 250V/10A)
2 on / off switch
