Franke COMPACT T 400 - Page 6

4
11-03-2014 / LSC 178 / Rev. 00
400
T
LEGEND
1. Top cup grid
2. Steam tap
3. Hot water tap
4. Touchpad
5. LED light display
6. Control panel
7. 2-cup filter holder
8. Air adjustment for milk foaming - M.A.T.
(optional)
9. Drip tray grid
10. Water drip tray
11. Boiler pressure gauge
12. Main on/off switch
13. Adjustable foot
14. Water mains gauge
15. Left steam wand
16. Water level glass
17. Hot water output
18. One-cup filter holder
19. Filling valve
20. Automatic steam delivery button for milk
foaming - M.A.T. (optional)
21. Steam wand with temperature sensor -
M.A.T. (optional)
T 400 MAT
Fig. 2
4 4
3
1 2
20
5
16
17
19
15
7
14
6
13
12
11
10
9
21
8
18
