2 EXPLANATION OF SYMBOLS
2.1 Symbols used in the manual
2.1.1 Orientation
Symbol Description
Clean components using the 5-step method.
This symbol indicates tips, tricks and additional information
Prerequisites for additional steps
Result or intermediate result for additional steps
2.2 Symbols used in the software
2.2.1 Symbols used for navigation and operation
Symbol Designation Description
Cancel button Cancel preparation
Select next/previous
page
Scroll through menus with multiple pages
Start button Start preparation
2.2.2 Symbols on the dashboard and on the user interface
Symbol Designation Description
Franke logo Call up the maintenance level
Bean left/right Active grinder
Double product Produce double beverage quantity (double production)
Energy-saving mode Switch the machine into energy-saving mode
