Franke Kaffeemaschinen AG Installation | 6
User manual Mytico Vario 25
*) Only for the grounds ejection option
Hose feedthrough in the counter
Minimum clearances
– To the rear panel: 50 mm
– Above: 300 mm (for filling and removal of the bean hopper)
– To the right: 300 mm (for opening the door)
NOTICE
Overheating damage
If the clearances around and above the machine are too small, heat may accumulate in the machine and
lead to faults.
a) Maintain the prescribed installation dimensions and clearances.
b) Take care to ensure that the clearance spaces are not blocked.
6.2.1 Feet
Mytico III is delivered with feet.
– Feet 60 mm (standard)
– Feet 140mm (option)
Adjustable feet can be used to compensate for unevenness or differences in height.
6.3 Requirements of the water supply
6.3.1 Main water connection
Water pressure 0.8-8.0 bar
Flow rate >100 ml/s
Water temperature <25 °C
Connection to the main water connection G3/8" compression fitting and metal hose l=1500
mm
Only connect with the hose kit provided
