FRANKIA OPERATING MANUAL22 FRANKIA OPERATING MANUAL 23
Using a new gas bottle for the first time:
• 1. Open the bottle valve (1).
• 2. Firmly press the hose rupture protection (3)
(green button) on the high-pressure hose for ap-
prox. 5 seconds.
• 3. After a false trigger, press the yellow reset button
(7) and turn it slightly clockwise and hold it for 5
seconds.
• (See also the Truma operating manual)
Opening and closing the system:
Opening the system:
• 1. Open the connected bottle
• 2.
Open the shut-off valve in the display cabinet or kitchen (depending on the floor plan) next to the entrance
• 3. Switch on the device
We advise against opening the shut-off valve of a device when you are not using it.
If a device does not work, repeat this process in the order mentioned above.
Closing the system:
Close devices, stopcocks and gas bottles.
• The space in the gas bottle box is only reserved for gas bottles. Do not use it as additional storage
space
• The forced ventilation in the bottom of the gas box must not be closed!
Commissioning of the gas tank (option):
• 1. Open the tank valve.
• 2. Press the Crash sensor firmly (green button).
• 3. After an accident or a false trigger, press the
green reset button on the MonoControl CS (reset
the crash sensor trigger element).
If the gas tank is installed with gas bottles in addition to the
gas box, select the gas source on the 3-way valve.
The 3-way valve is mounted near the gas distributor.
3.3 Gas stove
Turn the gas tap to the left while pressing. Keep the button pressed until the gas ignites. Release after 10 seconds.
The roof hatch in the kitchen area provides optimum ventilation in connection with the slightly opened kitchen window.
The gas stove must not be used as a heater. If you use pots or pans with a long handle, make sure that
they do not protrude into the passage. The piezo ignition only works when the power supply is switched
on in the control panel.
Be sure to use pots of a suitable size. If the pots are too small, the flames can blow out over the rim of
the pot. With the lowered hob, pots or pans should never protrude beyond the work surface. The kitchen
worktop is damaged by heat transfer.
3.4 Heating – Hot water
The liquid gas heating in your motorhome is equipped with an electronically controlled fan and an integrated hot water
boiler. The same device therefore allows you to distribute warm air throughout the entire main body and to have 12 l of
hot water at all times. So you only have one device for heating and hot water. For more information on heating and hot
water, please refer to Chapter 6. Before use and maintenance, please study the enclosed operating instructions from
TRUMA.
Distributor
Gas bottles
Gas tank
