INSTALLATION AND SETUP
Programming: Advanced Setup > Security
26
Programming: Advanced Setup > Security
Programming: Advanced Setup > Administration
Mod
bus
RW RC Display Name Range Description
N/A Edit Passcode 00000 to 99999;
default = 00000
Set a five-digit passcode to protect the SubMonitor
Connect from unauthorized changes to Basic Setup and
Advanced Setup menus. A setting of 00000 disables the
passcode feature, making all menus accessible.
Mod
bus
RW RC Display Name Range Description
500 RW N Hardware >
External CT Ratio
0 - NONE (default)
1 - 150:5
2 - 200:5
3 - 250:5
4 - 300:5
5 - 500:5
6 - 600:5
7 - 800:5
8 - 1000:5
Turns Ratio for Installed External Current Transformers
(CT)
N/A RW N Display Com Trip Enabled (default) or
Disabled
Choose whether to use the Display Communications Loss
alarm or not.
N/A RW N Backlight 0% to 100%; default,=,80% Set the level of backlight for the display.
N/A RW N Contrast 0% to 100%; default,=,50% Set the level of contrast for the display.
506 RW Y Return States Power Fail Mode:
Last or Off (default)
Choosing Last causes the SubMonitor Connect to return
to the last state it was operating in prior to the power
failure.
102 RW N Reset
Parameters
Reset KWH: Press Enter to confirm resetting the KWH counter to zero.
103 RW N Reset Motor Time: Press Enter to confirm resetting the Motor Time counter
to zero.
104 RW N Reset Settings: Press Enter to confirm resetting all settings to Factory
Defaults.
N/A RW N Language Choose from:
• English (default)
• Spanish
• Italian
• Portuguese
• German
• French
Choose the preferred language interface for using the
SubMonitor Connect.
