24
6. Press the MENU button to enter the programming mode to view and change
parameter settings.
Result: The program code stops ashing. The message display shows a
selectable option or a numerical value.
7. Press the MENU button to change a selectable option or the PRESSURE
or RPM button to change a numerical value.
8. Press the SILENCE button to save the changes and exit the programming mode.
Result: The program code advances to the next code and ashes.
9. Repeat steps 5 through 8 as necessary.
10. Press the SILENCE button when the program code is ashing to exit.
CODE DESCRIPTION MESSAGE DISPLAY Press MENU button to
select; change value with
PRESSURE or RPM
P318 RPM limit for pressure
control
MAX RPM
LIMIT <> 2100
Table 4. Operator Password Protected Program Functions
Values shown are standard factory default and may vary with engine type selected.
