Figure 15. Mack TGA307/407 Wiring

Mack Harness Connections

Interface Information.

For V-MACK IV 07 and newer, the governor is designed to control engine throttle

directly over the SAE J1939 databus.

J1939 CAN Bus Control

VC4

VC5

J1939 (+)

J1939 (–)

Pin 4 Red Wire

Pin 5 Black Wire

12-Pin

Connector

(Refer to

Figure 4)

VECU

Connector C

Note: Refer to Figure 4. TGA 12-Pin Connector Wiring

for power and interlock wire connections.
