FR150A Series Multifunctional Compact Inverter
- 7 -
1.3 Configuration, Mounting Dimensions and Weight
◆FR150A (0.2~22kW)
W
H
D
W1
H1
H3
H2
d2
d1
Fig 1-3 FR150A (0.2~22kW) product size diagram
◆FR150A (30~160kW)
H
D
W
W1
H1
d1
d1
d2
Fig 1-3 FR150A (30~160kW) product size diagram
Table 1-3 Configuration, mounting dimensions and weight
Model.
External and Install dimensions (mm)
N.W
(kg)
W
H
D
W1
H1
H2
H3
Install
hole
d1
Install
hole
d2
FR150A-2S-0.2B
75
150
120
65
140
35
38.5
4.5
4.5
0.95
FR150A-2S-0.4B
FR150A-2S-0.7B
FR150A-2S-1.1B
FR150A-4T-0.7B
FR150A-4T-1.5B
FR150A-2S-1.5B
93
171
132
82
160
35
39
4.5
4.5
1.46
FR150A-2S-2.2B
FR150A-4T-2.2B
FR150A-4T-4.0B
