UNBOXING
ASSEMBLY
INSTRUCTIONS
A. UNBOXING
1. Position the package with the arrows on the side facing upward.
2. Raise up the top cover to unpack the package.
3. Verify that all items are present in the accessory box.
B. FRONT WHEEL ASSEMBLY
1. Remove the nuts & washers from the front wheel axle
2. Attach the front wheel axle to the front fork.
3. Slide the front wheel washers onto the front wheel axle, and tightly
fasten the axle nuts to secure the front wheel.
C. DISC BRAKE CALIBRATION
1. Bend down near the wheel to inspect for any squealing sounds
coming from the brake disc and pads.
2. Loosen up the screw so the brake hub can move freely.
3. Adjust the clearance between the brake pad and disc, and
ensure that there is enough clearance between them.
4. Inspect the wheel again to identify the source of the squeaking
sound and check if the issue is resolved.
D. HANDLEBAR ASSEMBLY
1. Ensure the stem is straightened up at a 90-degree angle.
2. Install the handlebar onto the stem.
3. Align and center the handlebar with the perfect angle facing you.
4. Fully tighten the screws on the side and top of handlebar.
E. SEAT ADJUSTMENT
1. Use the M3 Allen key to loosen the screws holding the display.
2. Install the bracket onto the handlebar and securely tighten
the screws using the M3 Allen key.
3. Connect the blue and green female connectors to their
corresponding male connectors.
F. PEDAL ASSEMBLY
1. Remove the sticker from the RIGHT crankset.
2. Install the RIGHT pedal onto the RIGHT crankset, following the
provided illustration. Rotate the pedal in a clockwise direction.
3. Use a wrench to securely tighten the RIGHT pedal.
4. Remove the sticker from the LEFT crankset.
5. Install the LEFT pedal onto the LEFT crankset, following the provided
illustration. Rotate the pedal in a counterclockwise direction.
6. Use a wrench to securely tighten the LEFT pedal.
