G. FRONT LIGHT ASSEMBLY
1. Connect the wire of the front light.
2. Unscrew the front light M4 screws off the front light stands.
3. Install the front light onto the front light stands.
H. BATTERY INSTALLATION
1. Insert the battery key into the keyhole.
2. Rotate the battery key in a counter-clockwise direction to switch it to the
"UNLOCK" mode, as shown in the provided illustration.
3. Gently pull the top part of the battery out of the down tube.
4. Remove the battery from the down tube.
*If you wish to install the battery, firmly press it against the down tube and
turn the battery key clockwise to the "LOCK" mode after you hear a "click
sound" when the battery is properly inserted into the tube.
I. BATTERY CHARGING
1. Open the rubber cover on the charging socket.
a. Place the charger on a flat and secure surface. Connect the output
plug from the charger to the charging port located on the side of the
battery section.
2. Insert the input plug into a power outlet. Charging will begin, and you will
see the LED charge status light on the charger turn red.
3. When the charging is complete and the charging indicator light turns
green, begin by unplugging the charger from the wall outlet. Next,
remove the charger's output plug from the bike's charging port.
J. INDOOR WORKING STATION
Front
1. Align the screw holes located at the lower end of the bike rack's main
body with the corresponding holes on the bottom tube of the bike
frame. Insert the screws into the aligned holes.
2. Screw in the hex socket countersunk screw and use a tool to tighten it
securely.
3. Install and tighten the four corners of the product following the
sequence described above.
Rear
1. Take out the training unit body, main frame crossbar, and parts package
from the box.
2. Align the holes on the main frame crossbar with the corresponding holes
on the training unit body. Insert the carriage bolt, place a flat washer, and
tighten the cap nut.
3. Use an open-end wrench to securely tighten the cap nut. Make sure the
nut is tightened before using the training unit.
47 48
K. START YOUR BIKE
1. Remove the protective sticker from the display.
2. Press and hold the start button located on the left-hand side to initiate
the bike's startup process.
Pioase checkthe"Quick Start Cuide that endosod wth yourpackage for
detailed and picturg nstusction.
