OPERATION
INSTRUCTION
The e-bike is equipped with front and rear disc brakes, which are
responsible for slowing down or stopping the bicycle. It is important to
note that when riding in low-traction conditions, it is recommended to
apply the rear brake before using the front brake.
• The front brake, controlled by the lever on the left-hand side of the
handlebar, provides the majority of the e-bike's stopping power.
• When slowing down on slippery surfaces, it is advised to use the rear
brake first before engaging the front brake. Additionally, ensure that all
installed items are properly torqued, tightened, and connected.
• Each brake lever is equipped with a signal wire that automatically turns
off the motor when either brake is being used. This feature helps prevent
unnecessary wear on the electric motor and battery (for NA Version).
A. BRAKE OPERATION
B. GEAR OPERATION
The e-bike is equipped with a multi-speed gear system. Use lower gears
when starting from a stop or traversing steep hills and higher gears when
riding at higher speeds. The gear shifter, located on the right side of the
handlebar, can be rotated to select the desired gear. It is worth noting that
the gear shifting system and the pedal assist control system are complete-
ly independent and do not affect each other's performance.
POWER ON
To power on the bike, securely install the battery pack and press the power
C. POWER ON/OFF OPERATION
PEDAL ASSIST CONTROL(PAS) ON/OFF
1. To turn on the Pas controller, press and hold the Power Button for 5
seconds. Make sure to have both feet off the pedals and the bike still, as
the sensor will calibrate upon turning on. The LCD display panel will turn
on and show the battery's charge level and selected pedal assist level.
2. To turn off the controller, press and hold the power button. The LCD
display panel will turn off, and no power assist will be provided to the rider.
PEDAL ASSIST CONTROL ADJUSTMENT
1. Upon turning on the bike, press the "PLUS" button to increase the assist
level. Continue pressing until PAS 3: SPORT mode is reached.
2. To decrease the assist level, press the "MINUS" button once. Keep pressing
to decrease the assist level one level at a time until PAS 0: No Pedal Assist
is reached. The default assist setting is level 0, which will be displayed
whenever the e-bike is powered off and back on.
Additional Information:
• When the battery pack level drops to 2 bars, it is recommended to
recharge the battery pack soon and select a lower pedal assist level.
• When the battery pack level reaches 1 bar, it is advisable to stop using the
throttle and recharge the battery pack.
D. PEDAL ASSIST CONTROL(PAS) OPERATION
button. Then, push and hold the power button on the left-hand side
control module interface for 3 seconds. The LCD display will illuminate,
indicating that the bike is powered up.
POWER OFF
To power off the bike, push and hold the power button for 3 seconds
when the bike is on. The LCD display will power down, and the bike will
shut off.
AUTOMATIC SHUTOFF
The electronic system also has an automatic shutdown feature that
activates after a set period of time. This duration can be adjusted in the
setup menu.
