FREUCAMP W5000 - Console Disassembly

18
3. Remove the fuse bracket and side cover.
4. Remove the three waterproof joints as
shown in the figure.
5. Remove the control panel and control box
6. Remove the console and fixing plates on
the left and right.
Console removal
