32
T-CODE“). If you have activated the programming of
pipe number and/or pipe length these will then also
be displayed and can be entered accordingly (select
symbols by pressing the MENU button and using
the arrow buttons and save data by pressing the
START button). You will then be asked to enter the
traceability barcode of Component 2. Programming
of pipe number and/or pipe length takes place as
described above. If you have not activated any addi-
tional text (see Section 5.9.3) you will once again be
reminded of the significance of scraping the pipe
by the question „PIPE PREPARED?“. Confirm by
pressing the START button (i.e. the pipe has been
prepared appropriately; see also Section 5.9.4). You
will access the start mode (the upper line in the
display will show the connected fitting to be fused,
the lower line will ask „START?“).
IMPORTANT!
At this point you will be able to use the blue
arrow button (up/down) to skip to the menu „ID
Data“ once again to ascertain that all relevant
data has been entered or to make last minute
changes. Press the STOP button to exit this sub-
menu.
Start the fusion process by pressing the START but-
ton.
IMPOR
TANT!
Programming of traceability data is automatic,
i.e. once programming is complete the display
will show the next step until you reach the start
of the fusion. If you have to/would like to disrupt
this process (e.g. because you wish to check
your entry data once again) use the blue arrow
buttons (right/left) back and forth in the pro-
gramming process to access individually en-
tered data/information.
FT_2377e_II_07_GB.qxd 13.02.2007 12:31 Uhr Seite 32
