QUANTUM
™
LX CONDENSER/VESSEL CONTROL PANEL
MAINTENANCE
090.560-M (MAY 2016)
Page 39
VESSEL PANEL DIGITAL I/O BOARD #1 PICTORIAL
DIPSWITCH SETTINGS SIGNIFY
BOARD IDENTIFICATION NUMBER
DIO
19200
PROGRAM VERSION
I/O COMMUNICATION
ACTIVITY LAMPS
MICROPROCESSOR
WATCHDOG LAMP
(BLINKS IF OK)
FUSE POSITION DETERMINES
INPUT OR OUTPUT
IN = INPUT OR UPPER LOCATION
OUT = OUTPUT OR LOWER LOCATION
Vessel 1 High Level Shutdown
Vessel 1 High Level Warning
Vessel 1 Operating Level 1
Vessel 1 Operating Level 2
Vessel 1 Low Level Warning
Vessel 1 Low Level Shutdown
Vessel 1 Compressor Running
Vessel 2 High Level Shutdown
Vessel 2 High Level Warning
Vessel 2 Operating Level 1
Vessel 2 Operating Level 2
INPUT MODULE
FUSE
5A
OUTPUT MODULE
INPUT MODULE
INPUT MODULE
INPUT MODULE
INPUT MODULE
OUTPUT MODULE
OUTPUT MODULE
OUTPUT MODULE
OUTPUT MODULE
INPUT MODULE
INPUT MODULE
INPUT MODULE
INPUT MODULE
INPUT MODULE
INPUT MODULE
OUTPUT MODULE
OUTPUT MODULE
OUTUT MODULE
OUTPUT MODULE
INPUT MODULE
INPUT MODULE
INPUT MODULE
INPUT MODULE
OUTPUT MODULE
OUTPUT MODULE
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
