VYPER
™
VARIABLE SPEED DRIVE
MAINTENANCE
100-200 IOM (FEB 09)
Page 61
305 HP SPARE PARTS LIST
1
PART DESCRIPTION FRICK PART #
U34 VSD LOGIC BD EPROM 60/50 HZ 639A0211H01
U40 VSD LOGIC BD SERIAL PROM 639A0211H02
U45 VSD LOGIC BD PROM (60 HZ) 639A0211H03
U45 VSD LOGIC BD PROM (50 HZ) 649A0211H04
U42 FILTER BD CONTROL EPROM (60 HZ) 649A0211H05
U42 FILTER BD CONTROL EPROM (50 HZ) 639A0211H06
U26 FILTER BD PROM 639A0211H07
FRICK INTERFACE BOARD - (FIB) 639A0211H08
VSD LOGIC BOARD 639A0211H09
UPGRADE, FIB TO LOGIC BOARD (Board Only) Note: A 639A0211H10
UPGRADE, FIB TO LOGIC BOARD (Board & Harness) Note: B 639A0211H67
CIRCUIT BREAKER, 400 AMP, 65ka (Before 06/2006) 639A0211H11
CIRCUIT BREAKER, 400 AMP, 65ka (After 06/2006) 639A0211H12
5 AMP CARTRIDGE FUSE (60 HZ) 639A0211H13
6 AMP CARTRIDGE FUSE (50 HZ) 639A0211H14
10 AMP CARTRIDGE FUSE 639A0211H15
15 AMP CARTRIDGE FUSE 639A0211H16
20 AMP CARTRIDGE FUSE 639A0211H17
INPUT RECTIFIERS, (1, 2, & 3 PHASE) ONE EACH KIT 639A0211H18
VSD POWER MODULE 639A0211H19
VSD POWER MODULE CHILL PLATE 639A0211H20
VSD POWER MODULE (COMPLETE KIT) 639A0211H21
OUTPUT CURRENT TRANSFORMER 639A0211H22
AC LINE INDUCTOR 639A0211H23
BUS PLATE KIT 639A0211H24
VOLTAGE TRANSIENT BOARD 639A0211H25
FUSES, VOLTAGE TRANSIENT BOARD 639A0211H26
SCR TRIGGER BD (60 HZ) 639A0211H27
SCR TRIGGER BD (50 HZ) 639A0211H28
VSD DC BALANCING RESISTOR 639A0211H29
COOLANT PUMP 639A0211H30
BUS SNUBBER CAPACITOR 639A0211H31
SNUBBER RESISTOR 639A0211H32
SHELL & TUBE HEAT EXCHANGER 639A0211H33
RELAY, CONTROL FAN/PUMP 639A0211H34
GASKETS, HEAT EXCHANGER 639A0211H35
COOLANT 639A0211H36
INTERNAL CABINET FAN 639A0211H37
SILCON PAD (THERMAL) 639A0211H38
TRANSFORMER 24 VDC 639A0211H39
CONTROL TRANSFORMER, 3KVA (60 KVA) 639A0211H40
CONTROL TRANSFORMER, 3KVA (50 KVA) 639A0211H41
BUS ISOLATOR BOARD 639A0211H42
2-WAY ELECTRONIC VALVE, 1 1/2” (Valve Only) 639A0211H60
3-WAY ELECTRONIC VALVE, 1 1/2” (Valve Only) 639A0211H61
ACTUATOR, ELECTRONIC VALVE 639A0211H62
KIT 2-WAY TO 3-WAY VALVE 639A0211H63
SNUBBER CAPACITOR 639A0211H64
CHILL PLATE TEMP SENSOR 639A0211H65
Contactor, 3-pole, 9 amp (Oil Pump/Blower Motor) 639A0211H68
Oil Pump Starter, Overload 639A0211H69
Blower Motor Starter, Overload 639A0211H70
Blower Motor Aux. Contact 639A0211H71
1. Shaded rows are recommended spare parts.
Note: A - If the drive was manufactured after 02-08 or does not use the Frick Interface Board (FIB) replace Logic
board with 639A0211H10.
Note: B - If drives uses the frick interface board (obscolete) replace the Frick Interface and the Control Logic Board
with 639A0211H67. This kit replaces both the FIB and Logic Board.
