Friedrich D30A Service And Parts Manual

—23—
6. REPLACEMENT PARTS LIST
• MODEL: D30A
130411 BASE ASSEMBLY, SELD(SINGLE) 3041A10028C
130910 CABINET ASSEMBLY, SINGLE 3091A20015D
131110 CASE ASSEMBLY, SINGLE 3111A10016F
330870 DRAIN PAN ASSEMBLY 3087A10011B
148380 TANK, ASSEMBLY, BUCKET 4839A10001D
152302 FILTER(MECH), AIR 5230A20026A
162615 SENSOR ASSEMBLY 6877A30013H
249950 CONTROL BOX ASSEMBLY 4995A10074F
264110 POWER CORD ASSEMBLY 6411A20001Y
266011 SWITCH ASSEMBLY, MICRO 6600A30003C
268712 PWB(PCB) ASSEMBLY, DISPLAY 6871A20279A
268714 PWB(PCB) ASSEMBLY, MAIN 6871A20162K
346811 MOTOR ASSEMBLY, SINGLE 4681A20040E
35211A TUBE ASSEMBLY, SUCTION SINGLE 5211A20812A
352113 TUBE, DISCHARGE 5210A21843A
354210 EVAPORATOR ASSEMBLY 5421A20131A
336600 HOUSING ASSEMBLY 3660A10003A
550140 ISOLATOR, COMP 5040AR4195A
552111 TUBE ASSEMBLY, CAPILLARY 5211A20814A
554030 CONDENSER ASSEMBLY 5403A20110A
554160 RE-COMPRESSOR, SET 2521C-A8626
359012 FAN, TURBO 5900A20032A
567502 O.L.P 6750C-0009E
349600 MOUNT, MOTOR 4960A20009A
667482 P.T.C, ASSEMBLY 6748C-0003D
135500 COVER(TOP) 3550A20162A
436500 HANDLE 3650A20003A
144410 CASTER ASSEMBLY, ROLLER 4441A30001B
238310 ESCUTCHEON 3831A20051C
235512 COVER, ASSEMBLY, DISPLAY 3551A10024A
349480 ORIFICE 4948A10023A
336610 HOUSING ASSEMBLY, SINGLE 3661A10019A
558511 DRIER ASSEMBLY 5851A30001A
REMARK
LOCATION
NO.
DESCRIPTION
PART NO.
D30A

Friedrich D30A Specifications

General

Brand	Friedrich
Model	D30A
Category	Dehumidifier
Language	English
