Friedrich D30A Service And Parts Manual

—3—
1. PREFACE
This Service Manual provides various service information, containing the mechanical and electrical parts etc.
This dehumidifier was manufactured and assembled under the strict quality control system.
The refrigerant is charged at the factory. Be sure to read the safety precaution prior to servicing the unit.
1.1 SAFETY PRECAUTIONS
• Disconnect power supply before servicing or replacing any electrical or non-electrical component.
• Do not cut off the grounding prong or alter the plug in any manner at any circumstances.
1.2 FEATURES AND DIMENSIONS
1.2.1 FEATURES
• Quiet operation
• High efficiency
• Adjustable humidistat
• Automatic defrost
• Automatic shut-off
• Bucket-full indicator light
• Easy roll casters
• Removable & large capacity bucket.
• Washable air filter
• Two-speed fan
• Drain hose connection.
1.2.2 DIMENSIONS (mm/in)
385 (15
3
/
16
) 340 (13
6
/
16
)
530 (20
14
/
16
)
385 (15
3
/
16
) 340 (13
6
/
16
)
600 (23
10
/
16
)
D30A/D40A Model D50A/D65A Model
Figure 1
HUMIDITY
CONTROL
FAN
SPEED
TIMER
BUCKET
FULL
High
Low
Continuous On.
4Hr. On/Off
2Hr. On/Off
POWER
HUMIDITY
CONTROL
FAN
SPEED
TIMER
BUCKET
FULL
High
Low
Continuous On.
4Hr. On/Off
2Hr. On/Off
POWER

Friedrich D30A Specifications

General

Brand	Friedrich
Model	D30A
Category	Dehumidifier
Language	English
